| Place of Origin: | CHINA |
|---|---|
| Brand Name: | JIAXIN |
| Certification: | UL/CUL |
| Model Number: | UL 2464 |
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | Steel wooden drum |
| Delivery Time: | 7-15 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100KM/Week |
| Place Of Origin:: | China | Brand Name:: | JIAXIN |
|---|---|---|---|
| Model Number:: | AWM 2464 | Certification:: | UL / CUL |
| Core Conductor：: | Bare Copper / Coated Copper, Solid Or Stranded | Size:: | 18AWG ~ 26AWG |
| Nos.of Core:: | 2~20 | Sheath:: | PVC |
Application
The cables are intended for a variety of applications where appliances or equipment, including heavy industrial equipment, require a flexible connection to power supply.
Construction
| Core Conductor | Bare Copper / Coated Copper, Solid or Stranded |
| Popular sizes | 2~20 core x 18~26AWG |
| Fire performance | VW-1 / FT1 |
| Insulation | PVC Compound |
| Jacket | PVC Compound |
| Temperature rating | -20C up to 80℃ |
| Approval | UL / CUL |
| Voltage suitable | 300V |
Standards Certificates
UL 758
Advantage
oil - resistant, UV resistant , flexible to power supply
We are capable of meeting the most strict delivery schedules according to per purchase order. Meeting the deadline
is always the top priority as any delay in the delivery of cable can contribute to overall project delay and cost overrun.
The cable is supplied in wooden reels, corrugated boxes, and coils. Cable ends are sealed with BOPP self-adhesive
tape and non-hygroscopic sealing caps to protect the cable end from moisture. The required marking shall be printed
with a weather-proof material on the outsides of the drum according to customers' requirements.
▼ CNAS Labortory
3S Safety Cable Advanced Institute of Technology with 7 laboratories, has been established in Finecredit Group,
including Electrical Performance Laboratory, Mechanical Performance Laboratory, Combustion Test Laboratory,
High Frequency Laboratory, etc. Equipped with over 50 advanced equipment and technologies.
